Raptor 4E Heavy
Electrically driven pump 4" for muddy water, sewage and contaminated water.
Request your quote Download the brochureThe Raptor 4E Heavy is an electrically driven pump, self priming and equiped with a vacuum pump. This pump group is equipped with Perrot quick couplings" male, and is suited for muddy water, sewage and contaminated water.
Specifications
- Type: Aeon Raptor 4E Heavy
- Applications: muddy water, sewage, contaminated water, …
- Max. pressure: 20 mwc
- Max. capacity: 162 m³/h
- Motor: 3 x 400V, 50 Hz
- Power output: 7,5 kW at 1.700 tr/min (+ 1,3 kW for vacuum pump)
- Nominal current: 17 A
- Free impeller passage: 75 mm
- Weight: 900 kg
- Dimensions: 1.635 x 990 x 1.482 mm
- Coupling: suction and discharge side: Perrot quick couplings 4" male
- Characteristics: compact dry self priming centrifugal pump, with vacuum pump, large free passage
- Equipment: vacuum and manometer, ball check valve on discharge, stackable chassis, lifting eye
- Control panel: control panel with frequency converter, possible 2 float switches and sensor for automatic operation
- Plug: 32A 5P male
